OPIM-800 | Heavy-Duty Power for AC Units & Industrial Tools | Solar-Ready Design

Pure Sine Wave   Inverter

Rated Power:

800W

Frequency:

50Hz / 60Hz

Peak Power:

1600W

Unit Size:

280*135*60mm

Waveform:

Modified Sine Wave

Unit Weight / G.W.:

1340g / 1800g

DC Input   Voltage:

12V / 24V

Box Size:

440*350*330mm

AC output Voltage:

110V / 220V

Quantity/CTN:

8PCS

Model

OPIM-800-1

OPIM-800-1

OPIM-800-1

OPIM-800-2

OPIM-800-2

OPIM-800-2

Rated power

800W

Peak power

1600W

Input voltage

DC12V

DC24V

DC48V

DC12V

DC24V

DC48V

Output voltage

100VAC or 110VAC or 120VAC±5%

220VAC or 230VAC or 240VAC±5%

Unload current less than

0.8A

0.5A

0.2A

0.8A

0.5A

0.2A

Output frequency

50Hz±0.5Hz or 60Hz±0.5Hz

Output waveform

Modified Sine Wave

Waveform distortion

THD<3%(Linear load)

USB port

5V 1A

Max.efficiency

90%

Input voltage range

10-15.5V

20-31V

40-61V

10-15.5V

20-31V

40-61V

Low voltage alarm

10.5±0.5V

21±0.5V

42±1V

10.5±0.5V

21±0.5V

42±1V

Low voltage protection

10±0.5V

20±0.5V

40±15V

10±0.5V

20±0.5V

40±15V

Over voltage protection

15.5±0.5V

31±0.5V

61±1V

15.5±0.5V

31±0.5V

61±1V

Low voltage recover

13±0.5V

24±0.5V

48±1V

13±0.5V

24±0.5V

48±1V

Over voltage recover

14.8V±0.5V

29.5V±0.5V

59V±1V

14.8V±0.5V

29.5V±0.5V

59V±1V

Protection function

Low voltage

Alarm at first, voltage continously reduce. LED Red   light on & shut sown.

Over voltage

LED Red light on, shut down

Over load

LED Red light on, shut down

Over temperature

Alarm at first, tempurature continously rise.LED   Red light on & shut sown

Short circuit

LED Red light on

Input reverse polarity

Fuse burn-out

Working temperature

-10°- +50°

Storage temperature

-30°- +70°

Dimension(mm)

280x135x60mm

Packing(mm)

330x185x85mm

Net./gross weight(g)

1340/1800g

QTY/Ctn

8 Pcs

Meas./Ctn(mm)

440x350x330mm

Gross weight/Ctn(g)

15000g

Warranty

2 years

Configuration

Standard

Cooling method

Intelligent air cooling

Note

Our products update constantly.The technical parameter is for reference   only.Please refer to our real product.
