The 300W S-300 Single Output Power Supply is designed for devices requiring stable DC power. It offers a 5V output with 60A current to meet high-demand applications. With an input voltage range of 85-264VAC, this power supply is versatile in different environments. It operates with high efficiency (above 82%) and provides excellent protection against short circuits, overheating, overloads, and overvoltage. This unit ensures stable power output with less than 80mV ripple and noise. It's CE, RoHS, ISO9001, and FCC certified, ensuring top-quality performance.
SPECIFICATIONS | |||||||||||
OUTPUT | |||||||||||
Model | S-300-5 | S-300-7.5 | S-300-12 | S-300-13.5 | S-300-15 | S-300-24 | S-300-27 | S-300-48 | |||
DC Voltage | 5V | 7.5V | 12V | 13.5V | 15V | 24V | 27V | 48V | |||
Rated Current | 50A | 40A | 25A | 22.2A | 20A | 12.5A | 11.1A | 6.25A | |||
Current Range | 0-50A | 0-40A | 0-25A | 0-22.2A | 0-20A | 0-12.5A | 0-11.1A | 0-6.25A | |||
Rated Power | 250W | 300W | 300W | 299.7W | 300W | 300W | 299.7W | 300W | |||
Ripple & Noise | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | |||
Voltage Adj. Range | -10%,+12% | ±20% | -16%,+10% | -12%,+11% | -10%,+20% | -16%,10% | -4%,+18% | -15%,+17% | |||
Voltage Tolerance | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |||
Setup, Rise, Hold Up Time | 200ms,50ms,20ms at full load | ||||||||||
INPUT | |||||||||||
Voltage Range | 90~132VAC/180~264VAC selected by switch 47~63Hz; 254~370VDC | ||||||||||
AC Current | 6.5A/115V 4A/230V | ||||||||||
Efficiency | 73% | 76% | 74% | 79% | 78% | 81% | 82% | 83% | |||
Inrush Current | Cold start 50A/115V 50A/230V | ||||||||||
Leakage Current | <3.5mA/240VAC | ||||||||||
PROTECTION | |||||||||||
Over Load | 105%~135% | ||||||||||
Protection type: Fold back current limiting, recovers automatically after fault condition is removed. | |||||||||||
Over Voltage | 115%~135% | ||||||||||
Protection type: hiccup mode, recovers automatically after fault condition is removed. | |||||||||||
Over Temp. | RT3≥55℃ Fan On, ≤45℃ Fan Off, ≥80℃ Output Shutdown (5~7.5V) | ||||||||||
RT3≥65℃ Fan On, ≤55℃ Fan Off, ≥80℃ Output Shutdown (12~15V) | |||||||||||
RT3≥70℃ Fan On, ≤60℃ Fan Off, ≥85℃ Output Shutdown (24~48V) | |||||||||||
ENVIRONMENT | |||||||||||
Working Temp., Humidity | -10℃~+50℃; 20%~90%RH | ||||||||||
Storage Temp., Humidity | -20℃~+85℃; 10%~95%RH | ||||||||||
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | ||||||||||
SAFETY | |||||||||||
Withstand Voltage | I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | ||||||||||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | ||||||||||
STANDARD | |||||||||||
Safety Standard | Design refer to UL1950 | ||||||||||
EMC Standard | Design refer to EN55022, EN55024, EN61000 | ||||||||||
OTHERS | |||||||||||
Dimension | 215*115*50mm(L*W*H) | ||||||||||
Weight | 1Kg | ||||||||||
Packing | 20pcs/20Kg | ||||||||||
NOTE | |||||||||||
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2.Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor. 3.Tolerance: includes set up tolerance, line regulation and load regulation | |||||||||||
Protection Functions: Includes short circuit, overtemperature, overload, and overvoltage protection to ensure safety for both the power supply and connected devices.
Efficiency: With an efficiency greater than 82%, this power supply maintains optimal energy use even during high power output.
Wide Operating Temperature: It operates in environments ranging from -10°C to 60°C, making it adaptable to various conditions.
Low Ripple & Noise: Ripple and noise are kept under 80mV, ensuring stable and clean power output for sensitive devices.
High Efficiency: Maintains optimal performance while minimizing energy loss.
High Reliability: Designed for long-term, stable operation.
Multiple Protection Features: Includes overload, overvoltage, and overtemperature protection.
Certifications: CE, RoHS, ISO9001, and FCC compliant, meeting international standards and environmental regulations.
Servers: Provides stable DC power for continuous operation.
Communication Devices: Ensures reliable power for networking equipment.
Industrial Control Systems: Powers equipment that requires stable and efficient power input.
1.What is the efficiency of the 300W S-300 Single Output Power Supply?
The efficiency is greater than 82%, ensuring optimal energy use during high power output.
2.What protection features does the power supply offer?
It includes overload, overvoltage, overtemperature, and short-circuit protection to safeguard your equipment.
3.What applications is this Single Output Power Supply suitable for?
It's ideal for servers, communication devices, and industrial control systems that require stable DC power.
4.What certifications does the 300W S-300 Single Output Power Supply have?
It is CE, RoHS, ISO9001, and FCC certified, meeting international standards and environmental requirements.
5.What is the operating temperature range of this Single Output Power Supply?
The power supply operates in environments ranging from -10°C to 60°C.
