SPECIFICATIONS | ||
OUTPUT | ||
Model | DR-240-24 | DR-240-48 |
DC Voltage | 24V | 48V |
Rated Current | 10A | 5A |
Current Range | 0-10A | 0-5A |
Rated Power | 240W | 240W |
Ripple & Noise | 80mVp-p | 150mVp-p |
Voltage Adj. Range | 24-28V | 48-53V |
Voltage Tolerance | ±1% | ±1% |
Line regulation | ±0.5% | ±0.5% |
Load regulation | ±1% | ±1% |
Setup, Rise Time | 800ms,40ms/230VAC 800ms,40ms/115VAC at full load | |
Hold Up Time | 24ms/230VAC 24ms/115VAC at full load | |
INPUT | ||
Voltage Range | 85~264VAC 47~63Hz; 120~370VDC | |
AC Current | 2.8A/115V 1.4A/230V | |
Efficiency | 84% | 85% |
Inrush Current | Cold start 27A/115VAC 45A/230VAC | |
Leakage Current | <3.5mA/240VAC | |
PROTECTION | ||
Over Load | 105%~150% rated output power | |
Protection type: Constant current limiting, recovers automatically after fault condition is removed | ||
Over Voltage | 30-36V | 54-60V |
Protection type: Shut down o/p voltage, re-power on to recover | ||
Over Temp. | Protection type: Shut down o/p voltage, recovers automatically after temperature goes down | |
ENVIRONMENT | ||
Working Temp., Humidity | -10℃~+70℃; 20%~90%RH non-condensing | |
Storage Temp., Humidity | -20℃~+85℃; 10%~95%RH | |
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | |
SAFETY | ||
Withstand Voltage | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | |
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC | |
STANDARD | ||
Safety Standard | Design refer to UL508,UL60950-1, TUV EN60950-1, EN60950/UL60950 | |
EMC Standard | ENIEC 61558-1:2019/EN61558-2-16:2009+A1:2013 EN62368-1:2020+A11:2020 EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A2:2019+A14:2019/EN62233:2008 | |
OTHERS | ||
Dimension | 125.5*125.2*100mm(W*H*D) | |
Weight | 1.2Kg | |
Packing | 12pcs/15.5Kg/1.29CUFT | |
NOTE | ||
Technical Specifications and Guidelines:
| ||
Downloads：
DRP-240.doc
Industrial Automation
Provides a stable power supply for critical equipment such as PLCs, sensors, actuators, and other components essential for automation processes.
Intelligent Building Control Systems
Offers power support for various smart devices, monitoring systems, and control equipment, ensuring seamless operation of intelligent building infrastructures.
Traffic Control
Supplies power to equipment used in industries like railways and power distribution, ensuring reliable operation of traffic management and control systems.
Robot Systems
Delivers stable power to industrial robot control systems, supporting the precision and reliability required in robotic operations.
Measurement and Detection Equipment
Provides a consistent power supply for measuring instruments and detection equipment, ensuring accuracy and stability in data acquisition.
Medical Equipment
Medical Monitoring Equipment
Supports devices such as bedside monitors, blood pressure monitors, electrocardiographs, ventilators, and other essential patient monitoring equipment.
Diagnostic Equipment
Rail power supplies are commonly used to power control and imaging systems in medical diagnostic equipment like CT scanners and MRI machines.
Power and Energy Distribution Systems
Ensures a reliable and stable power supply for energy distribution networks, contributing to efficient and uninterrupted power management.
Smart Home Systems
Smart Home Controllers
Provides power for sensors, lighting control systems, temperature management, and other automation devices in smart homes.
Smart Locks and Smart Doorbells
Supplies power to smart access control systems, including smart locks, video doorbells, and monitoring devices, enhancing convenience and security.
Consulting Services
Purpose: To provide customers with expert technical guidance, enabling them to fully understand and leverage the benefits of Endpoint Detection and Response (EDR) products.
Key Responsibilities:
Deliver personalized technical consultations tailored to meet the unique needs of each customer.
Respond to customer inquiries about the usage and functionality of EDR products.
Enhance customer knowledge of product features, empowering them to use the software efficiently and effectively.
Remote Assistance
Purpose: To provide practical support that resolves technical challenges and ensures the smooth operation of EDR products.
Key Responsibilities:
Assist customers with software installation and initial setup using remote control tools or online guidance.
Help optimize product performance by supporting configuration adjustments.
Identify and resolve common technical issues quickly and efficiently, minimizing disruption during usage.
Abnormal output voltage:
When the voltage regulation control circuit inside the power supply is faulty, such as sampling resistance, error sampling amplifier, optical coupler, power control chip and other components damage or performance degradation, the output voltage will be too high or too low.
Excessive ripple:
aging, failure or capacity reduction of the filter capacitor will increase the ripple component in the DC voltage output by the power supply and affect the normal operation of the load equipment. Installation
problems:
The installation size of the guide rail power supply does not match the guide rail of the equipment, or it is not correctly stuck in the guide rail during the installation process, which will lead to the power supply cannot be firmly installed in the equipment, affecting the safety and stability of use.
