The S-35-5 35W Single Output Power Supply by Leyu is a highly efficient solution designed to meet the needs of various applications such as CCTV, industrial equipment, and smart homes. It ensures reliable and consistent performance, offering 5V output with a current of 7A to power your devices effectively.
With its wide input voltage range of 85-132VAC and 170-264VAC, this power supply can adapt to different regional voltage standards. It operates with 70% efficiency, minimizing energy loss and optimizing power usage.
The S-35-5 is equipped with essential protection features, including overvoltage, overtemperature, and overload protection, ensuring the safety and longevity of your connected devices. It is also ISO and CE certified, guaranteeing the highest quality and compliance with international standards.
Its compact size (129×98×38 mm) allows for easy installation in space-constrained environments, making it an ideal choice for various professional and personal applications. Whether for industrial machinery or smart home systems, the S-35-5 offers the performance and reliability you need.
SPECIFICATIONS | |||||
OUTPUT | |||||
Model | S-35-5 | S-35-9 | S-35-12 | S-35-15 | S-35-24 |
DC Voltage | 5V | 9V | 12V | 15V | 24V |
Rated Current | 7A | 3.6A | 3A | 2.4A | 1.5A |
Current Range | 0-7A | 0-3.6A | 0-3A | 0-2.4A | 0-1.5A |
Rated Power | 35W | 32.4W | 36W | 36W | 36W |
Ripple & Noise | 75mVp-p | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
Voltage Adj. Range | -5%,+10% | ±10% | ±10% | ±10% | ±10% |
Voltage Tolerance | ±2% | ±1% | ±1% | ±1% | ±1% |
Setup, Rise, Hold Up Time | 200ms,100ms,30ms at full load | ||||
INPUT | |||||
Voltage Range | 85~132VAC/170~264VAC selected by switch 47~63Hz; 240~370VDC | ||||
AC Current | 0.8A/115V 0.45A/230V | ||||
Efficiency | 70% | 72% | 76% | 78% | 78% |
Inrush Current | Cold start 18A/115V 36A/230V | ||||
Leakage Current | <2mA/240VAC | ||||
PROTECTION | |||||
Over Load | 110%~150% | ||||
Protection type: Fold back current limiting, recovers automatically after fault condition is removed | |||||
ENVIRONMENT | |||||
Working Temp., Humidity | -10℃~+60℃; 20%~90%RH | ||||
Storage Temp., Humidity | -20℃~+85℃; 10%~95%RH | ||||
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | ||||
SAFETY | |||||
Withstand Voltage | I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | ||||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | ||||
STANDARD | |||||
Safety Standard | Design refer to UL1012 | ||||
EMC Standard | Design refer to FCC Part15 J Conduction Class B | ||||
OTHERS | |||||
Dimension | 129*98*38mm (L*W*H) | ||||
Weight | 0.41Kg | ||||
Packing | 30pcs/13.4Kg/0.86CUFT | ||||
NOTE | |||||
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2.Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor. 3.Tolerance: includes set up tolerance, line regulation and load regulation | |||||
Wide Input Voltage Range: Supports 100V-220V AC input voltage, compatible with voltage standards in various regions.
High Efficiency and Power Density: 76% conversion efficiency reduces energy loss and heat, while the compact size (129mm×98mm×38mm) fits space-constrained applications.
Advanced Protection Features: Includes overload protection (115%-150% return current limit with auto recovery) and leakage current protection (<1mA/240VAC).
High Dielectric Strength: Withstands input-to-output voltage of 1.5kVAC for 1 minute, input-to-ground 1.5kVAC for 1 minute, and output-to-ground 0.5kVAC for 1 minute.
Wide Operating Temperature Range: Operates in temperatures from -10°C to +60°C with relative humidity from 20% to 90%, suitable for diverse environmental conditions.
Wide Voltage Conversion: Converts 100V-220V AC input to DC output, supporting multiple voltage options (5V, 12V, 15V, 24V).
Efficient and Compact: Ideal for applications requiring high efficiency, small size, and reliability.
Single Voltage Output: Each unit supports one fixed output voltage, ensuring consistent and stable power.
CCTV Systems: Powers surveillance equipment reliably for continuous operation.
Laboratories: Provides stable DC power for scientific instruments and research.
Industrial Equipment: Supports machinery and tools in industrial settings that need consistent power.
Smart Homes: Supplies power for various home automation systems and devices.
LED Lighting: Powers energy-efficient LED lighting systems for residential or commercial use.
3D Printers: Delivers consistent power for 3D printing applications.
General Industrial Devices: Suitable for a wide range of industrial applications requiring stable power supplies.
1. What is the input voltage range of the S-35-5 Single Output Power Supply?
The S-35-5 Single Output Power Supply supports an input voltage range of 85-132VAC and 170-264VAC, making it suitable for various regional voltage standards.
2. What is the output voltage and current of the S-35-5?
This single output power supply provides a stable 5V DC output with a current of 7A to efficiently power your devices.
3. What protection features are included with the S-35-5?
The S-35-5 single output power supply includes protection features such as overvoltage protection, overload protection, and overtemperature protection to ensure the safety and longevity of your devices.
4. What is the efficiency of the S-35-5 single output power supply?
The S-35-5 operates with 70% efficiency, which helps minimize energy loss and reduce heat generation.
5. What applications is the S-35-5 single output power supply suitable for?
The S-35-5 is versatile and can be used in various applications, including CCTV systems, industrial equipment, smart homes, LED lighting, and 3D printing.
